Pascal's device for gases

Dating

25 June 1952

The principle of Pascal (1653) is true for the " perfect fluid " and for fluids at rest. This tool allows to check how the pressure in a fluid (here the air, a gas) is transmitted in all directions (other devices also demonstrate that it is transmitted with the same intensity). By pressing the plunger, the level of the mercury (removed for security reasons) in all the pressure gauges rises simultaneously.

Web page

Pascal's device for gases

Cataloghi	Nº	Voce
Inv. 2016	258	Pascal's device for gases Provisional numbering!
Inv. 1870	1008	Apparecchio di Pascal per la trasmissione della pressione nei gas

Section

Gas

Window

Conditions

Complete

Working D

Intact

Large	13.0 cm (5.1 in)
Width	6.0 cm (2.4 in)
Height	39.0 cm (15.4 in)

Materials

Sources

Daguin P. A., Cours de physique élémentaire avec les applications a la météorologie , E. Privat, Toulouse, 1863, pag. 107, fig. 118
Felice M., Elementi di fisica, Ditta G. B. Paravia e Comp., Torino, 1887/90, Vol. 1, pag. 286, fig. 96
Galileo Officine, Apparecchi per l'insegnamento della fisica, Officine Galileo, Firenze, 1929, pag. 66, fig. 5131
Magrini R., Apparecchi per l'insegnamento della fisica, Officine Galileo, Firenze, 1940, pag. 74, fig. C403
Martelli V., Apparecchi per l'insegnamento della fisica, Soc. Italiana Apparecchi scientifici, Milano, 1956, pag. 13, fig. 155
Resti E., Catalogo generale di apparecchi per l'insegnamento della fisica, Ditta Emilio Resti di Franco Brambilla, Pubblicazi, Milano, 1930, pag. 27, fig. 120
Tarquini A., Apparecchi di fisica, Antonio Tarquini, Roma, 1928, pag. 34, fig. 153
