Plate with pressure gauge for pneumatic machine

Dating

20 October 1921

Plate with pressure gauge for pneumatic machine

Web page

Plate with pressure gauge for pneumatic machine

Cataloghi	Nº	Voce
Inv. 2016	257	Plate with pressure gauge for pneumatic machine Provisional numbering!
Inv. 1870	903a	Manomatro per macchina pneumatica Costruito un prolungamento con colonna di sostegno per raccordo del Manometro a mercurio e del tubo di gomma della pompa

Section

Gas

Window

Non esposto

Conditions

Complete

Working NC

Intact

Large	49.0 cm (19.3 in)
Width	31.0 cm (12.2 in)
Height	52.0 cm (20.5 in)

Materials

Sources

Galileo Officine, Apparecchi per l'insegnamento della fisica, Officine Galileo, Firenze, 1929, pag. 84, fig. 583
Magrini R., Apparecchi per l'insegnamento della fisica, Officine Galileo, Firenze, 1940, pag. 87, fig. D509
Tarquini A., Apparecchi di fisica, Antonio Tarquini, Roma, 1928, pag. 45, fig. 2575

The additional indications which integrate the items of the conservation's state have the following meaning: (?) = maybe complete; M = maintenance; P = partial; R = restored; D = used for teaching; NC = not checked; X = impossible to verify.
