Magnetoelectric machine with Pacinotti's ring

Dating

30 May 1941

Maker

Antonio Cherubini

It is a device, with a basic realization of its parts, that reproduces an electromagnetic rotating machine worcking both as a dynamo and as anelectric motor. Its fundamental element is the so called Pacinotti's ring.

Web page

Magnetoelectric machine with Pacinotti's ring

Cataloghi	Nº	Voce
Inv. 2016	579	Magnetoelectric machine with Pacinotti's ring Provisional numbering!
Inv. 1870	972	Piccolo anello di Pacinotti completo che funziona come motore e come dinamo

Section

Electrodynamics

Window

Conditions

Complete

Working NC

Intact

Large	23.0 cm (9.1 in)
Width	11.0 cm (4.3 in)
Height	13.0 cm (5.1 in)

Materials

The additional indications which integrate the items of the conservation's state have the following meaning: (?) = maybe complete; M = maintenance; P = partial; R = restored; D = used for teaching; NC = not checked; X = impossible to verify.
